8个星光1024喷头（80PL）
★星光SGI024高速工业级的打印喷头，更好地满足工业化生产需求
★负压式墨路控制系统以及墨水脱气系统的应用，大大提升了喷墨的稳定性
★配备导带自动清洁系统，保证连续生产，提高生产效率
★主动收/放卷结构，确保面料稳定的伸展性和收缩性
8 starfire 1024 print head（80PL）
★Starfire SGI024 high-speed industrial-grade print nozzles can better meet the needs of industrial production
★The application of negative pressure ink circuit control system and ink degassing system greatly improves the stability of inkjet
★Equipped with an automatic cleaning system for the guide belt to ensure continuous production and improve production efficiency
★Active rewinding/unwinding structure to ensure stable stretch and shrinkage of the fabric
XC08-08配置 |
打印喷头 Printer head | 8个星光1024喷头
8 PCS Starfire 1024 Print head |
适合面料厚度
Print width | 2-50mm范围内可调
2-50mm range is adjustable |
最大印花宽度
Max. Print width | 1900mm/2700mm/3200mm |
最大面料幅宽
Max. Fabric width | 1950mm/2750mm/3250mm |
生产模式
Production mode | 130㎡/h(2pass) |
图像类型
Image type | JPEG/TIFF/BMP文件格式，RGB/CMYK颜色模式
JPEG/TIFF/BMP file format, RGB/CMYK color mode |
墨水颜色
Ink color | 十色可选：黑，青，红，黄，浅青，浅红，灰，大红，橙，宝蓝。
Ten colors optional:CMYK/CMYK LC LM Grey Red Orange Blue. |
墨水的种类
Types of ink | 活性/分散/涂料/酸性/还原性墨水
Reactive/Disperse/pigment/Acid/reducing ink |
RIP 软件
RIP Software | Neostampa/Wasatch/Texprint |
介质传送
Transfer medium | 导带连续式传送，自动收卷
Continuous conveyor belt, automatic winding |
喷头清洗
Head cleaning | 全自动清洗装备，全自动刮墨设置
Auto head cleaning & auto scraping device |
功率
Power | 整机≦18KW（主机10KW 加热8KW)独立烘箱10KW(可选） power≦18KW (Host 10KW heating 8KW)extra dryer 10KW(optional) |
电源
Power supply | 380VAC±10%,三相五线
380vac plus or mius 10%,three phase five wire. |
压缩空气
Compressed air | 气流量≥0.3m3/min,气压≥6KG
Air flow ≥ 0.3m3/min, air pressure ≥ 6KG |
工作环境
working environment | 温度18-28度、湿度50%-70%
Temperature 18-28 degrees, humidity 50%-70% |
尺寸
Size | 3655(L)*2485(W)*1520MM(H)(门幅1900mm）, 4555(L)*2485(W)*1520MM(H)(门幅2700mm） 5600(L)*2485(W)*1520MM(H)(门幅3200mm） |
重量
Weight | 2500KGS(DRYER 750kg门幅1800mm)2900KGS(DRYER 900kg门幅2700mm) 4000KGS(DRYER门幅3200mm 1050kg) |
